Synced from Product Parameters V2: Basic & Appearance
| Recommended printing conditions | Nozzle Temperature280–320 °CRecommended Nozzle Diameter0.4-1.0 mmRecommended build surface treatmentPEI or Coating with PVP glueBuild plate temperature60-80 °CChamber TempSupports printing without sealingCooling fan speedOffPrint speed30-120 mm/sRetraction distance1-3 mmRetraction speed1800-3600 mm/minRecommended Support MaterialFusFree™ S-Multi Quick-Remove SupportDrying setting100-120℃ for 4-6hAnnealing80-100℃ for 4-8h |
|---|
| | Nozzle Temperature280–320 °CRecommended Nozzle Diameter0.4-1.0 mmRecommended build surface treatmentPEI or Coating with PVP glueBuild plate temperature60-80 °CChamber TempSupports printing without sealingCooling fan speedOffPrint speed30-120 mm/sRetraction distance1-3 mmRetraction speed1800-3600 mm/minRecommended Support MaterialFusFree™ S-Multi Quick-Remove SupportDrying setting100-120℃ for 4-6hAnnealing80-100℃ for 4-8h |
|---|
Printing Tips：Although the moisture absorption of PET material is very low, it is very sensitive to moisture. Printing after absorbing moisture will result in ozzing, extruding with bubbles and rough surface appearance, thus reducing print quality. It is recommended that put the filament into a dry box (humidity below 15%) immediately after opening the FusForce™️ PET-CF vacuum foil bag for printing. Please put the unused filament back into the original aluminum foil bag for sealed storage.After the material is damp, there will be more printing ozzing, bubbles extruded and rough printing surface. Please dry the filament in an oven at 100-120°C for 4-6h to restore the printing quality of FusForce™️ PET-CF.Phaetus hardened steel and above grade nozzles shall be selected, which can effectively improve the print quality. Besides, it is recommended that the thickness of the heating block should no less than 12mm.After the printing, the printed part can be annealed to further improve the strength of FusForce™️ PET-CF print part. Annealing conditions: place the printed part at 80-100°C for 4-8 hours and cool to room temperature naturally.
No matching print profile files.
Synced from the linked Product Parameters V2 record — use as a starting point for slicing and test prints.
Core temperature, speed and cooling settings from Product Parameters V2.
Nozzle, build plate and pre-print preparation recommendations.
Support material, spacing and compatible material recommendations.
FusRock 3D printing materials in the Lighting segment, illustrated by “Application: Astronomical applications—Making a reflecting telescope”, balancing structural strength, print fidelity and field reliability.
FusRock 3D printing materials in the Robotics segment, illustrated by “Robotic arm robot cable fixed protection limit sleeve”, balancing structural strength, print fidelity and field reliability.
No FAQs for this product yet.
General safety (FusRock)
| How to route filament |
|
||
|---|---|---|---|
| Moisture control |
|
| Short breaks | Store in a sealed dry box or apply a simple vacuum pack; avoid direct sunlight. |
|---|---|
| Long-term storage | Return filament to the factory foil bag, squeeze out air (add a fresh desiccant pack if available), then place inside a household vacuum bag and pull vacuum. Keep in a cool, dry place away from sunlight. |
PTC compact dryer box: 60–70 °C for 4–6 hours.
Small lab oven (forced-air): temperature uniformity is often limited; spools can warp. Reduce temperature/time (example: 40–45 °C for ~4 hours) and cross-check the material-specific drying notes in the datasheet.
Important: if print quality does not improve, test with an empty spool before raising temperature—non-uniform heat can deform plastic flanges.
Large forced-air oven: 60–70 °C for 4–6 hours.
PS: Why do devices differ? Add an internal article or external link (“learn more”).
⚠ Read before drying
(Insert “warped vs normal” spool photos here.)
What moisture does to prints
| Dry | Damp |
|---|---|
| Cleaner surface, stable color, mechanical properties on spec | Pitting, stringing, whitening, weaker properties (material dependent) |
(Optional: 1 / 2 / 3 day exposure at ~80% RH — same test part.)
* Example photos may reference a specific grade (e.g. PAHT-CF); label yours accordingly.
