Synced from Product Parameters V2: Basic & Appearance
| Recommended printing conditions | Nozzle Temperature250-270°CRecommended Nozzle Diameter≥0.2 mmRecommended build surface treatmentGlass、PEI Film or PC FilmBuild plate temperature100-110°CChamber TempSealing or 60-80°CCooling fan speedOff-30 %Print speed30-120 mm/sRetraction distance1-5 mmRetraction speed1800-3600 mm/minRecommended Support MaterialFusFree™ S-Multi Quick-Remove SupportDrying setting70℃ for 5-6hAnnealingN/A |
|---|
| | Nozzle Temperature250-270°CRecommended Nozzle Diameter≥0.2 mmRecommended build surface treatmentGlass、PEI Film or PC FilmBuild plate temperature100-110°CChamber TempSealing or 60-80°CCooling fan speedOff-30 %Print speed30-120 mm/sRetraction distance1-5 mmRetraction speed1800-3600 mm/minRecommended Support MaterialFusFree™ S-Multi Quick-Remove SupportDrying setting70℃ for 5-6hAnnealingN/A |
|---|
Printing Tips： 1. Compared with PLA, PETG and other materials, ABS materials need a higher chamber temperature to help release the residual stress during the printing process. Please keep the printer chamber closed during the printing process. It can effectively avoid printed parts from warping and cracking. If the device has a heated chamber, it is recommended to set the temperature of heated chamber between 60-80°C. 2. If the ABS-GF filament has been unpacked for a long time and the printing quality starts to degrade during the printing process, please dry the filament at 70-80°C for 4-6 hours before printing. 3. Although FusFunTM ABS-GF has much less odor compared with similar products, it is still recommended to place the printer in a well-ventilated area during printing.
No matching print profile files.
Synced from the linked Product Parameters V2 record — use as a starting point for slicing and test prints.
Core temperature, speed and cooling settings from Product Parameters V2.
Nozzle, build plate and pre-print preparation recommendations.
Support material, spacing and compatible material recommendations.
FusRock 3D printing materials in the Automotive segment, illustrated by “Electric vehicle conductive component connector verification inspection tool”, balancing structural strength, print fidelity and field reliability.
FusRock 3D printing materials in the Outdoor Durability segment, illustrated by “Rescue ship application case”, balancing structural strength, print fidelity and field reliability.
FusRock 3D printing materials in the RC Aircraft & Drones segment, illustrated by “Application cases of remote-controlled unmanned aircraft”, balancing structural strength, print fidelity and field reliability.
FusRock 3D printing materials in the Industrial Parts segment, illustrated by “Daily accessories or industrial parts storage box”, balancing structural strength, print fidelity and field reliability.
FusRock 3D printing materials in the Tabletop Games segment, illustrated by “Customized mechanical keyboard”, balancing structural strength, print fidelity and field reliability.
No FAQs for this product yet.
General safety (FusRock)
| How to route filament |
|
||
|---|---|---|---|
| Moisture control |
|
| Short breaks | Store in a sealed dry box or apply a simple vacuum pack; avoid direct sunlight. |
|---|---|
| Long-term storage | Return filament to the factory foil bag, squeeze out air (add a fresh desiccant pack if available), then place inside a household vacuum bag and pull vacuum. Keep in a cool, dry place away from sunlight. |
PTC compact dryer box: 60–70 °C for 4–6 hours.
Small lab oven (forced-air): temperature uniformity is often limited; spools can warp. Reduce temperature/time (example: 40–45 °C for ~4 hours) and cross-check the material-specific drying notes in the datasheet.
Important: if print quality does not improve, test with an empty spool before raising temperature—non-uniform heat can deform plastic flanges.
Large forced-air oven: 60–70 °C for 4–6 hours.
PS: Why do devices differ? Add an internal article or external link (“learn more”).
⚠ Read before drying
(Insert “warped vs normal” spool photos here.)
What moisture does to prints
| Dry | Damp |
|---|---|
| Cleaner surface, stable color, mechanical properties on spec | Pitting, stringing, whitening, weaker properties (material dependent) |
(Optional: 1 / 2 / 3 day exposure at ~80% RH — same test part.)
* Example photos may reference a specific grade (e.g. PAHT-CF); label yours accordingly.
