Synced from Product Parameters V2: Basic & Appearance
| PropertyTesting methodTypical valueDensityISO 11831.01 g/cm³HardnessISO 761995AMelt index235°C，2.16kg 30 g/10minWater absorptionISO 62:Method 11.69 %Vicat softening temperatureISO 306104.6 °CBayshore reboundASTM D263270 %Tensile breaking strength (X-Y)ISO 52727.64±0.88 MPaelongation at break (X-Y)1018.82±88.27 %tensile stress at 100% (X-Y)8.18±0.09 MPatensile stress at 200% (X-Y)8.89±0.10 MPatensile stress at 300% (X-Y)9.52±0.13 MPaCharpy impact strength at +23°CISO 179未冲断Non-breakCharpy impact strength at -30°C未冲断Non-breakTear Strength (Z)ISO 34-184.91±6.61 KN/mSpecimens printed under the following conditions: Nozzle size 0.4mm，Nozzle temp 240°C, Bed temp 100°C, Print speed 60mm/s, Infill 100%, Infill angle ±45° | Recommended printing conditions |
|---|
No matching print profile files.
Synced from the linked Product Parameters V2 record — use as a starting point for slicing and test prints.
Core temperature, speed and cooling settings from Product Parameters V2.
Nozzle, build plate and pre-print preparation recommendations.
Support material, spacing and compatible material recommendations.
No FAQs for this product yet.
General safety (FusRock)
| How to route filament |
|
||
|---|---|---|---|
| Moisture control |
|
| Short breaks | Store in a sealed dry box or apply a simple vacuum pack; avoid direct sunlight. |
|---|---|
| Long-term storage | Return filament to the factory foil bag, squeeze out air (add a fresh desiccant pack if available), then place inside a household vacuum bag and pull vacuum. Keep in a cool, dry place away from sunlight. |
PTC compact dryer box: 60–70 °C for 4–6 hours.
Small lab oven (forced-air): temperature uniformity is often limited; spools can warp. Reduce temperature/time (example: 40–45 °C for ~4 hours) and cross-check the material-specific drying notes in the datasheet.
Important: if print quality does not improve, test with an empty spool before raising temperature—non-uniform heat can deform plastic flanges.
Large forced-air oven: 60–70 °C for 4–6 hours.
PS: Why do devices differ? Add an internal article or external link (“learn more”).
⚠ Read before drying
(Insert “warped vs normal” spool photos here.)
What moisture does to prints
| Dry | Damp |
|---|---|
| Cleaner surface, stable color, mechanical properties on spec | Pitting, stringing, whitening, weaker properties (material dependent) |
(Optional: 1 / 2 / 3 day exposure at ~80% RH — same test part.)
* Example photos may reference a specific grade (e.g. PAHT-CF); label yours accordingly.
